Tube laser cutting machine ACME-Laser LT-6035
NeufACME-Laser · LT-6035
Caractéristiques techniques
Marque
ACME-Laser
Modèle
LT-6035
Année
2026
Description
Condition: new, functionality: fully functional, Year of construction: 2026, control type: PLC-controlled, degree of automation: semi-automatic, actuation type: electric, laser type: fiber laser, laser source manufacturer: Max Photonics, laser power: 6,000 W, sheet thickness (max.): 15 mm, pipe diameter (max.): 240 mm, pipe length (max.): 6,050 mm, working length: 6,050 mm, working width: 240 mm, working height: 240 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 6,800 mm, travel distance Z-axis: 250 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 100 m/min, feed rate Z-axis: 60 m/min, positioning accuracy: 0.05 mm, repeat accuracy: 0.03 mm, workpiece weight (max.): 300 kg, input frequency: 50 Hz, type of input current: three-phase, type of cooling: water, compressed air connection: 8 bar, total length: 16,000 mm, total width: 4,470 mm, total height: 2,450 mm, warranty duration: 12 months, Equipment: CE marking, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, safety light barrier, # Tube Laser LT6025G – High-Performance Tube Laser Cutting System with 3-Chuck Technology and Zero-Tailing System ## Precise Tube and Profile Processing at the Highest Level The LT6025G tube laser cutting system was developed for economical and highly precise processing of tubes and profiles. Thanks to state-of-the-art 3-chuck technology, powerful servo drives and an intelligent zero-tailing function, the system enables maximum material utilization while simultaneously ensuring the highest cutting quality. The machine is ideally suited for steel construction, metal construction, mechanical engineering, plant engineering, as well as for job shops and series manufacturers with the highest requirements for productivity and precision. --- ## Technical Data * Model: LT6025G * Tube Length: up to 6,000 mm * Tube Diameter: approx. Ø 10 – 250 mm * Clamping System: 3 fully automatic pneumatic chucks * Acceleration: up to 1.2 G * Positioning Accuracy: ± 0.05 mm / 1,000 mm * Repeatability: ± 0.03 mm / 1,000 mm * Cutting Gases: Oxygen, Nitrogen, Compressed Air * Drive System: High-dynamic Servo Drive Technology * Automatic Central Lubrication * Professional Tube Nesting Software * Robust Machine Construction for Continuous Industrial Use --- ## Processable Materials and Profiles The LT6025G processes a wide variety of tube and profile shapes: * Round Tubes * Square Tubes * Rectangular Tubes * Oval Tubes * Angle Steel * U-Profiles * Channel Profiles * Open Profiles * Special Profiles --- ## Zero-Tailing Technology The innovative zero-tailing system reduces the unavoidable scrap section to a minimum, thereby significantly increasing material utilization. This is particularly advantageous with high-priced materials, resulting in a noticeable reduction in production costs and sustainably improving profitability. --- ## Your Advantages at a Glance ✔ Modern 3-chuck clamping system for maximum precision Csbezb Irvszpcl Sehb ✔ Minimized material waste thanks to zero-tailing technology ✔ High dynamics and productivity through 1.2 G acceleration ✔ Excellent cutting quality and clean cut edges ✔ Precise drilling, contours and cutouts in a single operation ✔ Fast changeover for different profile shapes ✔ Reduction of rework and grinding effort ✔ High process reliability in series production ✔ Suitable for single-part, small-batch and large-batch production ✔ Economical production with high flexibility --- ## Typical Applications * Steel Construction * Metal Construction * Mechanical Engineering * Plant Engineering * Vehicle Construction * Commercial Vehicle Construction * Furniture and Profile Manufacturing * Job Shop Manufacturing * Tube Processing --- ## Inspection and Demonstration An inspection of the system and a test run with your components are possible at any time by prior appointment. We will gladly provide you with further technical documentation, videos, sample parts or an individual offer.
Machines de découpe laser proposées sous la marque ACME-Laser.
Une découpeuse laser découpe des tôles métalliques avec un faisceau laser haute puissance, offrant une précision élevée et des découpes complexes sans contact mécanique avec la matière. Utilisée en tôlerie industrielle, construction métallique, fabrication de pièces découpées sur mesure pour l'automobile, le bâtiment et l'électroménager. Le prix va de 30 000-80 000 € pour une découpeuse laser d'occasion de puissance moyenne à plus de 400 000 € neuf pour une machine haute puissance fibre dernière génération. Durée de vie de 10 à 20 ans, la source laser et les optiques étant les composants les plus coûteux à remplacer selon l'usage. Nécessite une alimentation électrique forte puissance, un système d'extraction des fumées, et un gaz d'assistance (azote, oxygène) selon le matériau découpé.
