Screen printing machine EMM

EMM · of input current: AC, overall weight: 1,500 kg, 1. very precise, fully automatic screen printing machine with an automatic feeder feeder that positions the sheet with an accuracy of 0.08mm. The integrated CCD camera recognizes a hole or a print mark and positions the screen with an accuracy of 0.02mm to the print mark. 2. welded steel frame and highly dynamic servo axes for maximum precision and smooth running 3. the printing table is made of cast aluminum with a flatness of ± 0.1 mm per meter 4. all guides are hardened linerar guides for a long service life 5. an integrated, controlled pneumatic squeegee pressure compensation, which acts directly on the individual squeegee holders, is able to level out even the smallest unevenness in the printed material. 6. the material is kept in a floating state during application and removal, which guarantees scratch-free transportation. Chjupd Sjqu Udws T Uob

Caractéristiques techniques

Description

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 150 h, input voltage: 400 V, total length: 6,000 mm, total width: 1,260 mm, total height: 2,130 mm, compressed air connection: 6 bar, type of input current: AC, overall weight: 2,500 kg, input current: 32 A, conveyor belt width: 550 mm, warranty duration: 12 months, roll width: 500 mm, 1. very precise fully automatic screen printing machine, which positions the motif with an accuracy of 0.03 - 0.05mm to the material. Chjupd S Tequ R Skj Ujb The integrated sensor recognizes the edge or print mark and positions the screen with an accuracy of 0.02mm to the sheet or print mark. It prints from roll to roll with unwinder + rewinder. UV drying and hot air drying up to 160 degrees Celsius are integrated 2. welded steel frame and very dynamic servo axes for maximum precision and smooth running 3. the printing table is made of cast aluminum with a flatness of ± 0.1 mm per meter 4. all guides are hardened linerar guides for a long service life 5. an integrated, electronically controlled pneumatic squeegee pressure compensation (option), which acts directly on the individual squeegee holders, is able to level out even the smallest unevenness in the printed material.
