Laser cutting machine Trumpf TCF 1

Trumpf · TCF 1

Caractéristiques techniques

Description

Condition: ready for operation (used), Year of construction: 2005, laser power: 2,000 W, ITEC Automation & Laser AG: Gantry Portal for Coil Line with Trumpf TCF 1 Laser + GSW AG Reel MHR 2.5 / 1250 + Straightening Machine VRMA 80 / 76 + Motoman ERCS-HP20-AE00 Robot The system will remain in operation until week 35. The system has been continuously maintained and partially overhauled in 2022. Sale is without extraction system and platform! TECHNICAL DETAILS Chjbjzu Avze T Tbd Hjb Trumpf TCF 1 MHR 2.5 / 1250 Wavelength: 10.6 µm Max. Output Power: 2,000 W Continuously adjustable power range: 100–2,000 W Power stability relative to rated power: ±2% Beam diameter at the output window: 26 mm Divergence angle (half angle): 0 mrad Power distribution: TEM₀₀ Pulse frequency: 10 Hz–100 kHz Marking mode frequency: 10 Hz Marking mode power: 80 W Pulse width: 10 µs–CW Reel MHR 2.5 / 1250 Load capacity: max. 2,500 kg Coil outer diameter: max. 1,250 mm Strip width: max. 600 mm Spreading range: min. 380 (480) mm Spreading range: max. 430 (530) mm Mandrel height: 1,000 mm Drive and Speed Speed: approx. 17.5 rpm Electrical drive power auxiliary drive: 1.1 kW Electrical Connection Connection voltage: 3 × 400 V Frequency: 50 Hz Noise Emission Noise level: 70 dB(A) EQUIPMENT Fixed rear edge Neutral conductor (N) and protective conductor (PE) Straightening Machine VRMA 80 / 76 Passage width: max. 100–800 mm Strip thickness: min. 0.4 mm Strip thickness: max. 1.5 mm Strip thickness at full width: max. 1.0 mm Number of straightening rolls: 7 Number of tension rolls: 2 Roller diameter: 60 mm Straightening roll spacing: 130 mm Speed: approx. 15 m/min Passing height above the floor: approx. 1,000 mm Drive type: Servo motor Electrical drive power: 2.2 kW Drive speed: 3,000 rpm Connection voltage: 3 × 400 V Frequency: 50 Hz Conductors: N, PE Noise level: 70 dB(A) Robot Motoman ERCS-HP20-AE00 Number of axes: 6 Load capacity: 20 kg Positioning repeatability: ±0.06 mm Weight: approx. 280 kg S-axis (rotation): ±180° L-axis (lower arm): +155° / -110° U-axis (upper arm): +255° / -165° R-axis (wrist rotation): ±200° B-axis (wrist bending): ±140° T-axis (wrist rotation): ±360° Speed S-axis: max. 2.96 rad/s / 170 °/s Speed L-axis: max. 2.96 rad/s / 170 °/s Speed U-axis: max. 3.05 rad/s / 175 °/s Speed R-axis: max. 6.20 rad/s / 355 °/s Speed B-axis: max. 6.02 rad/s / 345 °/s Speed T-axis: max. 9.16 rad/s / 525 °/s The height and weight of the asset must be considered when selecting the transport vehicle. A forklift is available for loading. If collection is not carried out on time, a storage fee of €20.00 per lot and day started will be charged. The fee must be paid before collection. The sale is made without any guarantee or warranty. The information on the technical data comes from the original offer. No guarantee is given for printing and measurement errors. If in doubt, please compare the information with the provided photos or inspect the goods on site before the end of the auction.
