Filling technology Grunwald GRUNWALD HITTPAC AKH-019R/1

Grunwald · GRUNWALD HITTPAC AKH-019R/1

Caractéristiques techniques

Description

Condition: as good as new (ex-display), Year of construction: 2023, functionality: fully functional, A used horizontal form, fill, and seal machine (HFFS) from the DEAPHS series is for sale. It is designed for the automatic production, filling, and sealing of pouches made from flat film. ### Current Machine Condition The machine is currently set up for the production of 4-side seal pouches. The machine forms the pouch directly from flat film, takes over the filling process – in conjunction with a suitable dosing system – and then automatically seals the pouch. The DEAPHS series is fundamentally modular in design and can be adapted for other pouch types and applications, depending on the existing or additional equipment, for example: - 3-side seal pouches / sachets - 4-side seal pouches - Doypack / stand-up pouches Adaptation to other pouch types depends on the format, product, and required machine components and is not part of the current setup. ### Possible Applications Depending on the dosing system used, the machine is suitable for packaging, for example: - Powdered products - Granules and granular products - Food products - Animal feed - Cosmetic products - Technical and other non-food products - Single-serve packs, sample sizes, and samples Different dosing and feeding systems can be used for different products. ### Machine Equipment - Independent film unwinding shaft - Pouch bottom sealing - Pouch bottom former - 3 horizontal sealing units - 2 vertical sealing units - Servo-controlled film/pouch feed - Mechanical pouch cut - Vacuum pouch opening - Photoelectric sensor control for printed film - LCD touchscreen display - Panasonic PLC - Servo film drive The separate film unwinding system enables controlled film tension and adjustment to different film widths and pouch formats. ### Possible Dosing Systems Depending on the application, the machine can be combined with the following dosing systems, among others: - Auger dosing - Volumetric cup filler - Multi-head combination weigher - Piston filler - Pump filler / liquid dosing, e.g., Hibar Availability and scope of delivery of the respective dosing systems can be requested separately. ### Technical Data Machine dimensions: approx. 5,500 × 1,100 × 1,400 mm (L × W × H) Net weight: approx. 2,000 kg Power supply: 380 V / 3 phases / 50 Hz Connected load: approx. 6.5 kW Air consumption: approx. 0.23 m³/min ### Installed Components / Manufacturers Components from, among others: Mitsubishi, Panasonic, Autonics, ABB, Airtac, and SMC Suitable packaging films, as well as other dosing, feeding, and peripheral equipment, can also be offered depending on the application. Inspection of the machine is possible by appointment. Cre Nm Tldeum R Ezoqjg Further information on pouch formats, working widths, possible dosing systems, and scope of delivery can be provided upon request.
