Edgebander SCM OLIMPIC K201

scm · OLIMPIC K201

Caractéristiques techniques

Description

Condition: new, Code: N0235 Brand: CASADEI INDUSTRIA Model: E 350 PM Automatic edge bander with hot melt (EVA) glue pot, chain panel feeding and pre-milling Maximum finishing quality Chain feeding system Pre-milling (E350PM) 3 free spaces for finishing units High performance 7 m/min feed speed 45 mm panel height 2 mm edge coils Minimum space occupied 2,30 m length Easy to use Unit settings with a piece of edge Easy and intuitive use of machine 3 position infeed fence 0-1-2 mm (according to edge thickness) Chain panel feeding Firm grip of panel guaranteed by special non-slip rubber on the pads. Linear feeding ensured by double sliding tracks with a special geometric profile accurately machined with precision to a hundredth of a millimetre. Long lasting monolithic frame fully processed only in one cycle on a CNC machining centre. Pressure bar with locking levers Top pressure bar with a double row of rubber wheels mounted on bearings, with locking levers and position indicator Pre-milling INVISIBLE GLUEING LINE DIAMOND tools Ø= 60mm H= 54mm HF motors 200 Hz – 12.000 rpm – 0.75 kW (each) Dedicated suction system and blower for panel cleaning before glueing Glueing unit PERFECT GLUEING, QUICK AND PRACTICAL SET-UPS 6 heating elements to guarantee uniform glue temperature. Motorized glue spreading roller with an internal electrical heating element. Inferior Teflon-coated glue pot to permit complete and rapid cleaning. Pneumatic shear, pressure rollers, edge feeding system DETAILS THAT MAKE THE DIFFERENCE Edge feeding synchronized with panel being processed Oscillatory movement of the cutting shear unit to guarantee perfect glueing Quick and precise positioning of the pressure rollers. The system “reads” the edge thickness, making mistakes impossible! Trimming cut-off PERFORMANCE AND VERSATILITY End trims front and rear excess edge Working cycle controlled by PLC Exclusion from control panel (PLC) Flush trimming unit Flush trimming unit with vertical disc copiers as standard Possibility of processing for edges from 0.4-2 mm Anti-adherence / release agent spraying unit (Opt.) INSTANT PERFECT CLEANING Spray function controlled by PLC Csupdsyvt Exj S T Uohb 2 sprayers (lower and upper) and liquid tank Infrared lamp (Opt.) TO GUARANTEE THE BEST GLUEING CONDITION Creates the best conditions for perfect glueing Heats panels and removes all traces of dampness.
